Compact Powerhouse

Despite its diminutive size, the MagicDot Neo delivers exceptional performance. Weighing just 6.6 kg, it houses a 120 W RGB-L multi-chip LED source coupled with a high-efficiency 100 mm optic, producing a total output of 3,000 lumens while consuming only 160 W of power. This efficient design results in an illuminance of 16,000 lux at 5 meters, offering a luminous intensity comparable to much larger fixtures.

Versatile Optics and Movement

The MagicDot Neo features a 10:1 zoom ratio, with a beam angle ranging from 3° to 30°, allowing for seamless transitions between beam and wash modes. Its continuous dual rotation on both pan and tilt axes enables fixtures to be clustered with minimal spacing, facilitating innovative configurations such as ultra-compact matrices or concentric circles.

High-Definition Liquid Effect™

A standout feature of the MagicDot Neo is its High-Definition Liquid Effect™, which incorporates 60 individually controllable RGB LEDs surrounding the beam's periphery. This design creates mesmerizing multi-color effects, generating organic light and complex volumetric visuals that elevate stage presentations to new artistic heights.

Built for the Future

Designed with durability in mind, the MagicDot Neo boasts an IP65 rating, ensuring reliable performance in various environmental conditions. Its lightweight construction is achieved through the strategic reduction of aluminum thickness, optimization of the cooling system, and integration of low-density optical parts. Extensive Ethernet connectivity supports unlimited system configurations, enhancing its adaptability in complex setups.

Specifications at a Glance

• Illuminance at 5m: 16,000 lux
• Zoom Aperture: 3° to 30°
• Front Lens: 100 mm
• Weight: 6.6 kg
• IP Rating: IP65
• CRI: Up to 86
• Rated Life (L70): Up to 40,000 hours
• Flicker-Free Operation: Suitable for TV applications and video-recorded events

‍

The MagicDot Neo is now available for demo!
